GIANT V6004T

GIANT V6004T

Ask
Ref. #
Contact form

Technical data and description

Standard version

  • Hitch: GIANT Standard (Hydraulically)
  • ROPS / FOPS safety roof, incl. safety doors left and right
  • Lifting arm with Z-kinematic
  • Double acting hydraulic valve at the front (mechanical)
  • Hydraulic servicebreak on 4 wheels
  • Floating position on lifting cylinder(s)
  • Luxury sprung seat with safety belt, armrest and extended backrest
  • Main switch
  • Towing hook at the back
  • 1 Counterweight integrated into the bumper
  • Working light on lifting arm
  • Cyclone filter
  • Oil cooler
Engine Kubota V2203M-T (4 cylinder),
Engine power 60 hp / 44 kW
Fuel Diesel
Service weight1 3,400 kg
Lifting capacity 2,500 kg
Tipping load2 2,200 kg
Lifting height2 3,292 mm
Length without bucket 3,790 mm
Width on standard tires 1,400 mm
Driving mechanism Hydrostatic 4 wheel drive with automotive control with 14 tons axles. Planetairy end drive.
Control Drive back and forward through electrical switch
Differential lock 100% electrical differential lock on both axles
Driving hydraulics 121.5 ltr/min (350 bar)
Working hydraulics 54 ltr/min (215 bar)
Driving speed 0-10 km/h, 0-28 km/h (with automatic gear)
Parking brake Drum brakes
Colour GIANT yellow / GIANT grey / black
